Mirco-Grid-KOWINT ENERGY - LiFePO4 Battery ESS Solution | ODM Service-Providing scalable, efficient LiFePO4 battery storage solutions for residential, commercial, and industrial applications, with a focus on sustainability and long-term energy independence.

60kWh Air-Cooling Battery

Pure Battery System
Module Energy(kWh)	5.12
Module Nominal Voltage(V)	51.2
Module Capacity (Ah)	100
Battery Module Combination	6S2P
System Nominal Voltage(V)	307.2
System Energy(kWh)	61.44
Discharge Current(A)	100
Charge Current(A)	95
Dimension(WDH)	7509502280mm / 29.537.489.7in
Weight Approximate	1050kg / 2314.8lb
Communication Interface	CAN, RS485, Wi-Fi, LTE
IP Rating	IP55
Storage Temperature(°C)	-20 ~ 35
Recommend Depth of Discharge	90%
Cycle Life	>8000 cycles
Warranty	3 Years Free, Paid From The 4th To The 15th Year
Certification	UL1973, UL9540A, UN38.3, IEC62619 UL 1741-2021(incl UL1741SB), CSA C22.2, No 107.1-16 IEEE 1547-2018 & 1547a-2020 & 1547.1-2020 (SRD V2.0), UL1699B

See Datasheet Get a quote

233kWh Liquid-Cooling Battery




Capacity(kWh)	233
Nominal Voltage(V)	832
Operation Voltage Range(Vdc)	702 ~ 949
Discharge Depth	90% DoD
Thermal Management Mode	Liquid Cooling
Thermal runaway management	Aerosol Extinguishing



Rated AC output power(kW)	125
Rated output voltage(Vac)	480
Output voltage range(Vac)	-15% ~ 10%(settable)
Adjustable power factor	＞0.99
THDi	＜3%
PCS Cooling	Forced Air Cooling
PCS Topology	non-isolation
AC/DC start function	Integration
Switch from Grid-connected to Off-grid	Integration
Communication Interface	CAN, RS485, WiFi, LTE
Warranty	3 Years Free, Paid From The 4th to The 15th Year
Certifications	IEC 62619, EN 61000-6-1/2/3/4 EN 62019-1/2, UL1973, UL9540A, UL9540, UN38.3
Dimensions(WDH)	110014502350mm / 435792.5in
Total Weight	2950kg /6503lbIP Rating
IP Rating	IP54

See Datasheet Get a quote




Capacity(kWh)	215
Nominal Voltage(V)	215
Operation Voltage Range(Vdc)	215
Discharge Depth	90% DoD
Thermal Management Mode	Liquid Cooling
Thermal runaway management	Aerosol Extinguishing



Rated AC output power(kW)	125
Rated output voltage(Vac)	480
Output voltage range(Vac)	-15% ~ 10%(settable)
Adjustable power factor	＞0.99
THDi	＜3%
PCS Cooling	Forced Air Cooling
PCS Topology	non-isolation
AC/DC start function	Integration
Switch from Grid-connected to Off-grid	Integration

See Datasheet Get a quote
