| Capacity(kWh) | 233 |
|
|
|
|
| Nominal Voltage(V) | 832 |
|
|
|
|
| Operation Voltage Range(Vdc) | 702 ~ 949 |
|
|
|
|
| Discharge Depth | 90% DoD |
|
|
|
|
| Thermal Management Mode | Liquid Cooling |
|
|
|
|
| Thermal runaway management | Aerosol Extinguishing |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Rated AC output power(kW) | 125 |
|
|
|
|
| Rated output voltage(Vac) | 480 |
|
|
|
|
| Output voltage range(Vac) | -15% ~ 10%(settable) |
|
|
|
|
| Adjustable power factor | ＞0.99 |
|
|
|
|
| THDi | ＜3% |
|
|
|
|
| PCS Cooling | Forced Air Cooling |
|
|
|
|
| PCS Topology | non-isolation |
|
|
|
|
| AC/DC start function | Integration |
|
|
|
|
| Switch from Grid-connected to Off-grid | Integration |
|
|
|
|
| Communication Interface | CAN, RS485, WiFi, LTE |
|
|
|
|
| Warranty | 3 Years Free, Paid From The 4th to The 15th Year |
|
|
|
|
| Certifications | IEC 62619, EN 61000-6-1/2/3/4 EN 62019-1/2, UL1973, UL9540A, UL9540, UN38.3 |
|
|
|
|
| Dimensions(W*D*H) | 1100*1450*2350mm / 43*57*92.5in |
|
|
|
|
| Total Weight | 2950kg /6503lbIP Rating |
|
|
|
|
| IP Rating | IP54 |
|
|
|
|
